Unitree G1 EDU is a next-generation bipedal humanoid robot designed for university education and research. Its open-source architecture enables full control and customization of both hardware and software.
Compact Power
It stands out for its advanced mobility of arms, legs, and torso, enabling the programming of complex movements. It facilitates the study of locomotion, dynamic control, and human–robot interaction in both real and simulated environments.
| Size(Standing) | 1098mm×450mm×645mm |
| Size(Lying Prone) | 880mm×460mm×330mm |
| Weight | 60kg Total weight (battery included) |
| Battery Performance | Battery capacity 45Ah(2250Wh)，voltage 58V |
| Endurance Ability | Battery life 4-6h Walking without load > 5h, and the mileage > 20km Walking with 20kg load > 4h, and the mileage> 15km |
| Wheeled Foot | Optional |
| Load(Standing) | Max. 120kg |
| Load(Walking) | > 40kg |
| Continuous Stair Climbing | Stairs of 20~25cm |
| Climbing Ability | Climb up and down stairs of 40cm in forward direction |
| Operating Temperature | -20℃ ~ 55℃ |
| Climbing Angle | > 45° |
| Running Speed | > 6m/s [1] |
| Ditch Jumping Width | 0.5~1.2m |
| Max Jump Distance | > 1.6m |
| Ingress Protection | IP67 |
| Control and Perception | Standard Configuration: Intel Core i5 (Platform Function), Intel Core i7 (User Development) Optional Configuration: Intel Core i7 and Jetson Orin NX (Maximum up to 3 devices) |
| Sensing Sensor | 3D LiDAR ×1 + Depth camera ×2 + Optical camera ×2 (Varies with different configurations) |
| External Interface | 1000M-Base-Ethernet×4 USB3.0×4 12V×4 5V×1 24V×4 BAT×1 |
Walks at 7 km/h
Expressive gestures
Recognizes faces
Programmable voice
Optional choreographies
